How do you mate splines in Solidworks?
For example, if you need to mate a clamp to a tube, add an axis in the center of the clamp. In the Assembly, show the sketch of the spline and the sketch of the reference geometry. In our example you would select each endpoint of the axis you created and add a Coincident Mate to the Spline. It’s that simple.
What is a linear coupler solidworks?
A Linear/Linear Coupler mate establishes a relationship between the translation of one component and the translation of another component. You can use Linear/Linear Coupler mates in SOLIDWORKS Motion. You can add the mates without having SOLIDWORKS Motion added in.
What does lock rotation do in Solidworks?
Use Lock Rotation Concentric mates and slot mates, as of SOLIDWORKS 2021, have a Lock Rotation option. This prevents a cylindrical part from being able to rotate on its axis and helps to fully define it.
What is lock mate in Solidworks?
A Lock mate maintains the position and orientation between two components. The components are fully constrained relative to each other. A Lock mate has the same effect as forming a subassembly between the two components and making the subassembly rigid.
In what way does a concentric mate constrain an assembly?
The concentric mating constraint eliminates two translational DOFs and two rotational DOFs. The coincident-mate mating constraint eliminates one translational DOF and two rotational DOFs.
How do I use collision detection in Solidworks?
To detect collisions as you move or rotate components: Click Move Component or Rotate Component (Assembly toolbar). In the PropertyManager, under Options, select Collision Detection. If the component you are moving touches any other component in the assembly, the collision is detected.
What is Profile Center mate in Solidworks?
Profile Center Mate automatically center-aligns geometric profiles to each other and fully defines the components. To create a profile center mate: In an assembly document with two rectangular or cylindrical profiles, click Mate . … For cylindrical profiles, click Lock Rotation to prevent the components from rotating.
How many entities can you choose to mate with an angle mate?
Click Mate (Assembly toolbar) or Insert > Mate. In the Mate PropertyManager, for Entities to Mate , select two entities in the graphics area or the flyout FeatureManager design tree. Under Standard Mates, click Angle and set the dimension.
How many types of mates are there in Solidworks?
Standard mates include angle, coincident, concentric, distance, lock, parallel, perpendicular, and tangent mates. Advanced mates include limit, linear/linear coupler, path, symmetry, and width mates. Mechanical mates include cam-follower, gear, hinge, rack and pinion, screw, and universal joint mates.
How do I lock a part in place in Solidworks?
Open the System Options, and on the General page check Enable Freeze bar. This adds the Freeze bar to the design tree in the Feature Manager. Drag the bar below the features you want to lock. Release your left mouse button, and the features are locked.
What is a tangent mate in Solidworks?
Standard Mates Perpendicular: Places selected items at a 90 degree angle from each other. Tangent: Places a cylindrical, spherical, or conical face tangent with another component. Concentric: Places two cylindrical, spherical or conical faces of a part so that they share the same centerline.
Which display mode is suitable for viewing only edge of a model in Solidworks?
Edge display in shaded with edges mode Use to accurately display thin-walled parts and assemblies and to prevent edges from blending. To use this option the graphics card and driver must support OpenGl 4.0, GLSL 4.0 or greater. All edges are shown in Shaded With Edges mode (like Wireframe).
Can we apply fixed angle mate between two curves?
You can control component motion in an animation by mating the component to a single entity curve, using coincident mates, or to a multiple entity curve, using path mates. You can also use a curve to define camera-based walk-through animations.
What is the difference between a mate and flush constraint?
What is the difference between a mate and flush constraint? Mate constrains two surfaces, or lines face to face. Flush aligns the two surfaces, and they are “flush” next to each other.
How do I make parts parallel in Solidworks?
on the Align toolbar, or click Tools > Dimensions > Align Parallel/Concentric .
