How do I draw a thick line in SolidWorks?
You can select the line thickness icon and you will get a drop down list of the 8 thicknesses available and a 9th option for a custom thickness. Once you click off of the drawing you should notice the change in thickness. This is the quick and dirty way of changing the line thickness.
How do you increase thickness in SolidWorks?
Click Thicken on the Features toolbar, or click Insert > Boss/Base > Thicken. Examine the preview, and select the side of the surface you want to thicken, as shown below. Enter the Thickness . Note that when you select Thicken Both Sides , it adds the Thickness you specify to both sides.
Which button is used to change the thickness of a line? Answer. blob brush tool is used to change the thickness of a line.
How do you show line thickness in CAD?
On the command line in AutoCAD, type LWDISPLAY and set the value to On (or 1). Alternatively, use the Show/Hide Lineweight button that can be added to the status bar. Note: On Page Setup, the setting Display plot styles can override expected lineweights depending on the plot style file chosen.
Where is thicken SolidWorks?
To thicken a surface: Click Thicken (Features toolbar), or click Insert > Boss/Base > Thicken. In the graphics area, select a Surface to Thicken . In the PropertyManager, under Thicken Parameters, select the side of the surface you want to thicken.
What is thicken in SolidWorks?
Creates a solid feature by thickening one or more adjacent surfaces. If the surface you want to thicken is comprised of multiple adjacent surfaces, you must first knit the surfaces together before you thicken the surface.
How do I fill between two surfaces in SolidWorks?
To create a filled surface, click Filled Surface on the Surfaces toolbar, or click Insert > Surface > Fill, set the PropertyManager options, and click OK .
How do I change the smart dimension in SolidWorks?
To change a dimension: Double-click a dimension. The Modify dialog box appears. Change the dimension value with the arrows, thumbwheel , mouse wheel, or by typing in the dimension box.
Which tool is used to select the thickness of a line?
“Blob brush tool” is the right approach.
How do you change the line thickness in AutoCAD 2021?
In the Plot Style Table Editor, Form View tab, select the plot style you want to change. Click the Lineweight arrow and select a lineweight from the list. To specify that the object’s lineweight should be used select Use Object Lineweight. Click Save & Close.
How do you reduce polyline thickness in AutoCAD?
How do you reduce polyline thickness in Autocad? Select the width option from the command line and enter the value of the width you want to apply on this polyline. Then press “Enter” twice to apply the change and exit the command.
Which type of line in a sheet should be the thickness in Solidworks?
To set line thickness: Click File > Print. In the dialog box, under Document Options, click Line Thickness. In Line thickness print settings, type a value for the line weights (Thin, Normal, Thick, and five additional line thickness settings).
How do I change the color of a sketch line in Solidworks?
To change the color of the sketch in your display, go to the FeatureManager design tree, right click Sketch > Sketch Color. This will take you to the Sketch/Curve Color property manager (see image below). Inside the property manager, you can set any desired color for the sketch.
How do you draw a phantom line in Solidworks?
First go to sketch, draw your line(s). Now right click in the grey part of the Command Manager and add the “Line Format” toolbar. Pick the line(s) you would like to make Phantom. Click the “Line Styles” Icon in the Line Format Toolbar and choose phantom.
What are layers in Solidworks?
You can create layers in a SOLIDWORKS drawing document. You assign visibility, line color, line thickness, and line style for new entities (annotations and assembly components) created on each layer. New entities are automatically added to the active layer.
